| Business Type | Manufacturer, Exporter, Supplier |
| Country of Origin | India |
| Type | Automatic |
| Material | Stainless Steel |
| Click to view more | |
Product Details
Warranty
1 Year
Certification
CE Certified
Phase
Single Phase
Driven Type
Electric
Voltage
220V
STANDARD EQUIPMENTS :
- Draw Bar
- Power Pack with Cylinder
- Electrical Control Panel with Switch Box & Motors
- Machine Lamp
- Bellow Covers & Base Splash Tray
OPTIONAL EQUIPMENTS :
- Extra Hydraulic Manifold for Clamp & Unclamp with Electrical
- Collet Adaptor Set
- Hydraulic Oil
- NC Controlled Rotary Table
- NC Control Dividing Head
- Spindle Taper ISO 50 Standard
- Milling Machine Vice
- Electric Coolant Pump & whichever not mentioned in standard
Note :
- Being committed to continual improvement, all specifications are subject to change without prior notice.
- We always focus to do customization/ automation in machines as per our customer’s need.
- Jig Fixtures, Tooling, Cutters & Inserts, Job Clamps etc. in buyer’s scope.
- Final Inspection is mandatory once before despatch from our factory to avoid unsought advices.
Specifications
| MODEL | HMS 500 | HMS 700 |
| Table Size | 1100 x 300 | 1300 x 300 |
| T-Slots/Bolt Size/C.D. | 3/M16/65 | 3/M16/65 |
| X-Traverse (Longitudinal) | 500 (Hydraulic Feed/Rapid) | 700 (Hydraulic Feed/Rapid) |
| Y-Traverse (Cross Traverse) | 200 (Manual) | 250 (Manual) |
| Z-Traverse (Vertical Traverse) | 300 (Manual) | 350 (Manual) |
| Table Loading Capacity | 200 Kgms. | 300 Kgms. |
| Spindle Taper Standard | ISO 40 | ISO 40 |
| Spindle Speeds & Range | 12 (45-1100 RPM's) | 12 (45-1100 RPM's) |
| Arbor Diameter | 25.4 mm | 25.4 mm |
| Feed Range | Hydraulic Variable | Hydraulic Variable |
| Rapid | Quick | Quick |
| Milling Spindle Motor | 2 HP | 3 HP |
| Hydraulic Power Pack Motor | 2 HP | 3 HP |
| Coolant System, if Required | 0.1 HP | 0.1 HP |
